AXIOM

  • 8+1 Ball Bering8+1 Ball Bering
    8+1 Ball Bering
    8+1 Ball Bering

    8 ball bearings, 1 roller bearing

  • Regular ball bearingRegular ball bearing
    Regular ball bearing
    Regular ball bearing

    Standard bearings in stainless steel.

  • Infinite anti-reverseInfinite anti-reverse
    Infinite anti-reverse
    Infinite anti-reverse


    The new system of a stopper of a return course instantly blocks return movement of a rotor without the slightest rollback back, guaranteeing a timely reliable cut

  • Cone bailCone bail
    Cone bail
    Cone bail


    The conical base of the arch of the woodcutter, preventing overlapping of the line along the support of the roller.

  • Computer balanced rotorComputer balanced rotor
    Computer balanced rotor
    Computer balanced rotor

    The newest system of computer balancing of the rotor, excluding the possibility of its beating during rotation and ensuring the soft operation of the mechanism.

  • Air bailAir bail
    Air bail
    Air bail

    A light hollow shackle of a wood scraper made of high-quality stainless steel. Reduces the vibration of the coil and allows you to smoothly close the arch of the forest tiller without impact.

  • Cast lockCast lock
    Cast lock
    Cast lock


    Locking system of the forester arch in open position, preventing spontaneous closing of the arch of the forest depositor during casting

  • Power gearPower gear
    Power gear
    Power gear

    Power transmission gear "steel on bronze", consisting of carbide specially treated steel gear and a sharp bronze screw screw, provides smooth operation of the mechanism and increased service life of the coil.

  • Antitwist rollerAntitwist roller
    Antitwist roller
    Antitwist roller


    The special design of the logging roller is specially designed to reduce twisting of the line when winding. When winding the coil, the fishing line is dumped into the technological groove of the roller and passes through one point, whereby the line does not have the ability to "hang" over the entire surface of the roller, which subsequently avoids the formation of loops during casting.

Specification

  • 8 ball bearings
  • 1 roller bearing
  • Instant anti-reverse system
  • Hollow Bail Arm
  • Cone Bail (prevents line twist)
  • Computer balanced rotor
  • Stainless Steel/Bronze power gear (bronze main gear with stainless steel pinion)
  • Antitwist Roller
  • Bail fix system Cast Lock
  • Machine cut aluminum handle
  • Graphite spare spool
ModelGear RatioBearingsWeight, g.Line Capacity, Ømm/m
BSA2000FD 5.2:1 8+1 210 0.185/200; 0.200/160; 0.250/105
BSA2500FD 5.2:1 8+1 250 0.200/200; 0.250/165; 0.280/125
BSA3000FD 5.2:1 8+1 260 0.235/230; 0.260/185; 0.300/100
